- Product Size
- Technical Specification
| UL-P-1009-C | ||
| 1 | LED Type and Quantity | 1*3W CREE XPE |
| 2 | LED quantity in series connection*in-parallel connection | 1*1 |
| 3 | LED BIN | VF=(3.0～3.2)V |
| 4 | CCT & CRI | 2700K/3000K/4000K/6000K Ra≥80 |
| 5 | SDCM | < 6 steps |
| 6 | Current for all LED | 0.125A(DC24V) |
| 7 | Current for each pc LED | 0.7A |
| Electricalelectronic | ||
| 1 | Rated Input Voltage & Frequency | DC12V/24V |
| 2 | System Power | 3W±10% |
| 3 | Control/Dimming | ONOFF PWM |
| Optical | ||
| 1 | System Lumen Package(typical) | 60 lm |
| 2 | System Efficacy(typical)lm/w | 20 LM/W |
| 3 | Beam Angle | asymmetric lens 15° 30°, 15° 14°, 15° 53°（tilt pan）
or General lens 10°, 15°, 18°, 22°, 25°, 30°, 40°, 60° |
| Mechanical & packaging | ||
| 1 | Luminaire Size (L*W*H) | Ø55×70 (mm)Diameter x length. The height of mounting sleeve is 98mm. |
| 2 | Weight per piece | 0.36 kgs |
| 3 | Packaging quantity | 30 |
| 4 | Packaging size | 46*28.5*24cm |
| 5 | Gross weight KG) | 11.5KG |
| Material & Finishing | ||
| 1 | Luminaire Body material & color | SS316 trim, Aluminium housing CNC machined, dark grey color |
| 2 | Material for Lens or Reflector | PMMA |
| 3 | in conformity with Rohs or not? | Yes |
| 4 | Glass | Stepped tempered glass, Thickness is 6mm |
| 5 | External cable size and length | 1PC rubber cable, neoprene material,H05RN-F 2x1mm2. The length is 1 meter. |
| 6 | Mounting Sleeve/ Spike/ Others | Black plastic, kettle shape. |
| Mounting | ||
| 1 | Surface/Recessed/Suspended/… | Recessed installation |
| 2 | cut-out size for on ground | Φ 80mm |
| Classification | ||
| 1 | Approbation | CE |
| 2 | IP | IP67 |
| 3 | IK | IK06 |
| 4 | Lum Classification | III |
| 5 | Working temp | -25℃～50℃ |
| 6 | Life time in hours | 50000h |
| 7 | Warranty years | 3 |
- Light Distribution Curve
- Lux Distance Curve
- Light Illustration
- Light Output
