- Product size
- Technical Specification
| UL-P-3001 | ||
| 1 | LED Type and Quantity | 3*2W CREE XPE |
| 2 | LED quantity in series connection*in-parallel connection | 3*1 |
| 3 | LED BIN | VF=(3.0～3.2)V |
| 4 | CCT & CRI | 2700K3000K4000K6000K Ra≥80 |
| 5 | SDCM | < 6 steps |
| 6 | Current for all LED | 0.25A(DC24V) |
| 7 | Current for each pc LED | 0.5A |
| Electricalelectronic | ||
| 1 | Rated Input Voltage & Frequency | DC24V |
| 2 | System Power | 6W±10% |
| 3 | Control/Dimming | ONOFF PWM |
| Optical | ||
| 1 | System Lumen Package(typical) | 110lm |
| 2 | System Efficacy(typical)lm/w | 18 LM/W |
| 3 | Beam Angle | One beam with 2° 2° 2° (similar with a door)° |
| Mechanical & packaging for front cover | ||
| 1 | Luminaire Size (L*W*H) | 116×72(mm) Diameter x Height |
| 2 | Weight per piece | 1.24kgs |
| 3 | Packaging quantity | 12 |
| 4 | Packaging size | 38*26*24CM |
| 5 | Gross weight KG) | 15.9kg |
| Material & Finishing | ||
| 1 | Luminaire Body material & color | SS316 trim, Aluminium housing CNC machined |
| 2 | Material for Lens or Reflector | Acryl |
| 3 | in conformity with Rohs or not? | Yes |
| 4 | External cable size and length | 1PC rubber cable of neoprene material, H05RN-F 2×1.0mm², the length is 1 meter |
| 5 | Glass | Tempered Glass, thickness is 8mm |
| 6 | Loading Capacity | 2000kgs |
| 7 | Mounting Sleeve/ Spike/ Others | Solid passivated (Anodizing) Aluminum CNC machined.Dark grey |
| Mounting | ||
| 1 | Surface/Recessed/Suspended/… | Recessed installation |
| Classification | ||
| 1 | Approbation | CE |
| 2 | IP | IP67 |
| 3 | IK | IK09 |
| 4 | Lum Classification | III |
| 5 | Working temp | -25℃～50℃ |
| 6 | Life time in hours | 50000h |
| 7 | Warranty years | 3 |
- Light Distribution Curve
- Illuminance Distance Curve
- Light Output
