- Product Size
- Technical Specification
| UL-P-3001-C | ||
| 1 | LED Type and Quantity | 4*1W CREE XPE |
| 2 | LED quantity in series connection*in-parallel connection | 4*1 |
| 3 | LED BIN | VF=(3.0～3.2)V |
| 4 | CCT & CRI | 2700K3000K4000K6000K Ra≥80 |
| 5 | SDCM | < 6 steps |
| 6 | Current for all LED | 0.035A(DC24V) |
| 7 | Current for each pc LED | 0.5A |
| Electricalelectronic | ||
| 1 | Rated Input Voltage & Frequency | AC100~265V |
| 2 | System Power | 5W±10% |
| 3 | Control/Dimming | ONOFF |
| 4 | Power Factor(PF) | ≧0.5 |
| 5 | Surge Protection | 1 kv: L-N/1 kv:LN-PE |
| Optical | ||
| 1 | System Lumen Package(typical) | 20~25lm |
| 2 | System Efficacy(typical)lm/w | 5 LM/W |
| 3 | Beam Angle | 300° x 5° |
| Mechanical & packaging for front cover | ||
| 1 | Luminaire Size (L*W*H) | 85×112(mm) Diameter x Height |
| 2 | Weight per piece | 0.44kgs |
| 3 | Packaging quantity | 20 |
| 4 | Packaging size | 37.5*20.5*32.5CM |
| 5 | Gross weight KG) | 9.8kg |
| Material & Finishing | ||
| 1 | Luminaire Body material & color | Anodzing Aluminium housing CNC machined |
| 2 | Material for Lens or Reflector | PMMA |
| 3 | in conformity with Rohs or not? | Yes |
| 4 | External cable size and length | 1PC rubber cable of neoprene material, H05RN-F 2×1.0mm², the length is 1 meter |
| 5 | Glass | Don’t have |
| 6 | Mounting Sleeve/ Spike/ Others | Screws |
| Mounting | ||
| 1 | Surface/Recessed/Suspended/… | Surface installation |
| Classification | ||
| 1 | Approbation | CE |
| 2 | IP | IP66 |
| 3 | IK | IK07 |
| 4 | Lum Classification | I |
| 5 | Working temp | -25℃～50℃ |
| 6 | Life time in hours | 50000h |
| 7 | Warranty years | 3 |
- Light Distribution Curve
- Illuminance Distance Curve
- Application
