360 degree nice light output LED Wall Light 4W

541 viewers

SKU: WL-P-E001 Category:
Share:
  1. Product Size:

2.Electric Property:

Item No.(UL-P-E001) WL-P-E001
Light Source18pcs of 2835 SMD LED chips
Power4W
Input Voltage24VDC
Color temperatureWarm White 3000K, Cool White 6000K
Beam angle360°
Lumens140lm to 150lm
CRI>80



  1. Specifications

1) Outdoor Wall Light, also used it as step light, stair light

2) Housing: Passivated 6063 aluminum

3) Front cover: Stainless steel 316L

4) Load capacity: 320kgs, people can step on the product, but car can not drive it over.

6) Power cable: Rubber cable of neoprene material, H05RN-F 2×0.75mm2 L=1.5m

7) Cable gland: PG7 cooper with nickel coated

8) Gasket: O-ring PMQ silicon seal

9) Driver: Constant current output

10) Operating temperature: -20 to +60 ℃

11) Mounting sleeve: Aluminum

12) IP Rating: IP67

13) Warranty: 3 years

  1. IES File:

5.Illuminance-distance Curve:

6..Light Output:
